Weight

• Net Weight:42kg(92.4lb)
• Gross Weight:52kg(110.5lb)
• Battery Weight:4.2kg(9.3lb)x2
• Weight limit:150kg(330lb) Payload Capacity

Size

• Product Size:1720x1130x750mm
• Packing Size:1500x340x800mm

General

• Classes:Class 4(Ebikes can go above 28mph with pedal assistance)
• Max Speed: 35MPH
• Range:up to 160 Miles by Pedal assist,80+ Miles by Throttle(Calculation based on rider's weight of 75kg. Range varies according to road condition, weather, rider's weight etc.)
• Pedal Assist:5 Levels

E-system

• Battery:Dual Removable Internal Lithium-ion Battery, 52V 23Ah, 760Wh
• Charger:52V 3 Amp Charger, Approx. 8 Hour Charging, Aviation Connector. UL LISTED
• Motor:Dual Rear Geared Hub Motor, Rated 1000w(peak),Max Torque 160NM
• Controller: 48V 25A Peak
• Display: Multifunctional LCD Smart Display
• Pedal Assist: Cadence Sensor
• Throttle: Twist Throttle
• Front Light:52V 10W LED Light, 30 LUX

Drivetrain

• Shifter: Shimano, 7-Speed
• Rear Derailleur: Shimano, Long Cage
• Crank & Chainring:48T, 170mm Alloy Crank
• Freewheel: 7-Speed
• Pedal: Alloy Platform Pedals

Components

• Saddle: Comfortable Wide Saddle
• Handlebar:Alloy, 750mm width
• Grips: Nylon Lock-on
• Brake: Front & Rear Hydraulic Disc Brakes
• Brake rotor: 180mm, 1.9mm thick
• Kickstand: Side Kickstand
• Seatpost: Forged Alloy, Ø30.4*350mm
• Stem:Bar bore: ∅31.8mm, Clamp I.D.: ∅28.6mm, HEIGHT: 40mm, RISE: 0°
• Handlebar:Aluminum Ø31.8mm, Width 710mm

Frameset

• Frame:Carbon Steel, Removable Battery, Internal Routing
• Fork: Hydralic Suspension Fork
• Fenders:Included

Wheels

• Rim Material: Aluminum
• Rim Size: 20 x 3.0
• Rim Type: Wheel with Integral Hub
• Tire:  Fat Tires
• Tire Size: 20" x 4.0"

Ebike x1

Battery x1

Charger x1

peddle x2

Tool Set x1

Manual X1

Bell & x1
